• Detailed Diagram of Effective Printing Range
3 (Bottom margin)
(1.75)
82.5 mm backing paper
1.75 ± 0.5
4.5 (T
op margin)
3 (Left margin) 3 (Right margin)
22.5 – 287.5 (Eff
ectiv
e pr
inting length)
30 – 295 (Label length)
35 – 300 (Blac
k mar
k pitch)
79 ± 0.5 (Label width)
82.5 ± 0.5 (Backing paper width)
73 (effective printing width:
48 characters with font A)
Dot numbers 39 – 622
*
Minim
um settab
le top margin when
paper is f
ed using bac
k-f
eed.
Effective printing range
(1.75) 1.75 ± 0.5
3 (Bottom margin)
(1.75)
79.5 mm backing paper
1.75 ± 0.5
4.5 (T
op margin)
3 (Left margin) 3 (Right margin)
22.5 – 287.5 (Eff
ectiv
e pr
inting length)
30 – 295 (Label length)
35 – 300 (Blac
k mar
k pitch)
76 ± 0.5 (Label width)
79.5 ± 0.5 (Backing paper width)
70 (effective printing width:
46 characters with font A)
Dot numbers 39 – 598
*
Minim
um settab
le top margin when
paper is f
ed using bac
k-f
eed.
Effective printing range
