3-7. Loading the Paper Roll
Be sure to use paper roll that matches the printer’s specification.
Cover open lever
Paper roll
Tension bar
1 Push the cover open lever and open the printer
cover.
2 Set the paper roll in the direction as shown, and pull
on the leading edge of the paper towards you.
Note: Make sure not to pass the paper under the
tension bar. In the following condition,
remove the tension bar unit and change the
adjustment lever position in accordance with
the procedures described in paragraphs --
and --:
• Paper thickness between 100 μm and 150
μm, or paper width of 57.5 mm on the
vertical/wall-mount layout
Note: When using a paper roll with an . mm
width, remove the paper roll holder in ac-
cordance with the procedure described in
paragraph --.
3 Push both sides as shown in order to close the
printer cover.
Note: When closing the printer cover, make sure
both sides close firmly, not just one side.
