Specifications
General points
4 Recording format:
Voice: Linear PCM (Pulse Code Modulation)
MP3 (MPEG-1 Audio Layer3)
Movie: MOV (MPEG-4AVC/H.264)
4 Recording medium:
SD card: 1 GB to 32 GB
4 No. of effective pixels:
2,930,000 pixels (16:9)
2,190,000 pixels (4:3)
4 Image pickup device:
1/4" 5-megapixel CMOS sensor
4 Lens:
Focal length f4.1mm
16:9 at 49mm
4:3 at 59mm
4 Shooting range:
30 cm to ∞
4 Movie resolution:
1080p 30fps, 720p 30fps, 480p 30fps
4 Photometric system:
Digital ESP metering, spot metering system.
4 Digital Zoom:
Max. 4x
4 Monitor:
2.0 color LCD display
4 Sampling frequency:
Linear PCM format
[96 kHz/24 bit] 96 kHz
[88.2 kHz/24 bit] 88.2 kHz
[48 kHz/16 bit] 48 kHz
[44.1 kHz/16 bit] 44.1 kHz
MP3 format
[320 kbps 44.1 kHz] 44.1 kHz
[ 256 kbps 44.1 kHz ] 44.1 kHz
4 Maximum headphone output:
â 150 mV (according to EN 50332-2)
4 Speaker:
Built-in ø 16 mm round dynamic speaker
4 MIC jack:
Input Jack [Microphone]:
ø 3.5 mm mini-jack, impedance 2.2 kΩ
Input Jack [Line]:
ø 3.5 mm mini-jack, impedance 39 kΩ
4 EAR jack:
ø 3.5 mm mini-jack, impedance 16 Ω or more
4 Connector
USB connector/HDMI micro connector (type D)
4 Maximum working output:
270 mW (8 Ω speaker)
4 Input power requirement:
Battery:
Lithium ion battery (LI-42B)
External power supply:
AC adapter (F-3AC) 5 V
4 External dimensions:
135 mm × 63 mm × 18.1 mm
(without protrusions)
4 Weight:
154 g (including battery and SD card)
4 Operating temperature:
0°C - 42°C/ 32°F - 107.6°F
Frequency response:
4 During recording mode
(Microphone jack):
Linear PCM format
[96 kHz/24 bit] 20 Hz to 44 kHz
[88.2 kHz/24 bit] 20 Hz to 42 kHz
[48 kHz/16 bit] 20 Hz to 23 kHz
[44.1 kHz/16 bit] 20 Hz to 21 kHz
MP3 format
[320 kbps 44.1 kHz] 50 Hz to 20 kHz
[256 kbps 44.1 kHz] 50 Hz to 20 kHz
