CD-100K Phonograph

2 - 3 4

21822666

If You “Get Lost” in the Menus

Since the menu mode of pricing and programming does not require you to use any reference material, you may
(occasionally) find that you have ventured down the wrong menu and that you don’t know what option is next. To
correct this situation, perform the following steps:

1. Press and hold down RESET and press 0 until you come to the top of current menu.

2. If this menu name doesn’t help, press and hold RESET and press POPULAR. This will move you to the top

of the previous menu. In most cases, this will return you to the main menu ( * SERVICE MODE * ).

3. If you still cannot determine where you are, press and hold RESET and press POPULAR again. Repeat this

step until you get to the main menu ( * SERVICE MODE * ).

USING CD-100K COMMANDS

CD-100K commands are formed by combining the numbers that appear on the left side of the menus in Figure 2-10.
To construct and use CD-100K commands, refer to Figure 2-10 or Table 2-4.

Example: You want to view the number of cycles the CD mechanism has made. Using Figure 2-10, you determine

that you need to select AUDITS (1) on the main menu; NON-RESETTABLES (2) on the AUDIT
menu; and MECH (7) on the NON-RESETTABLES menu. Use the digits to form a numeric command,
which is 127. Type 127 and the number of mechanism cycles is displayed.

Combining Menu and Modes

The most efficient way to set pricing and change programming is to use a combination of the menu mode and the
command mode to move through the menus. To do this, use the command mode to get to the command you want
to use, execute the command, and use the menu mode to go to your next selection.

NOTE:

To use the command mode effectively, return to the main menu after each command is
completed. Do this by holding
RESET down and pressing POPULAR until the words
*SERVICE MODE* appear on the digital display.
