CD-100K Phonograph

2 - 1 4

21822666

Table 2-1. Extension Speaker Worksheet

Sheet 3

8-OHM SPEAKERS CONNECTED TO TRANSFORMER TAPS

Place the quantity of speakers in the blank under QTY and multiply the quantity times the power consumption
(show stereo speakers as 2 speakers). Place your results in the blank under TOTAL.

8-Ohm Stereo Speakers connected to transformer taps

QTY

Total

Connections

Speakers for the .5 watt taps:

____at .5 watt each =

____watts

(E1 to E2)

Speakers for the 2 watt taps:

____at 2 watts each =

____watts

(E1 to E3)

Speakers for the 8 watt taps:

____at 8 watts each =

____watts

(E1 to E4)

Speakers for the 18 watt taps:

____at 18 watts each =

____watts

(E3 to E5)

Speakers for the 24 watt taps:

____at 24 watts each =

____watts

(E2 to E5)

Speakers for the 32 watt taps:

____at 32 watts each =

____watts

(E1 to E5)

Speakers for the 50 watt taps:

____at 50 watts each =

____watts

(E3 to E6)

Speakers for the 72 watt taps:

____at 72 watts each =

____watts

(E1 to E6)

Speakers for the 95 watt taps:

____at 95 watt each =

____watts

(E3 to E7)

8-Ohm Mono Speakers connected to transformer taps

Speakers for the 2 watt taps:

____at 2 watt each =

____watts

(E2 to E2)

Speakers for the 8 watt taps:

____at 8 watt each =

____watts

(E3 to E3)

Speakers for the 32 watt taps:

____at 32 watt each =

____watts

(E4 to E4)

Speakers for the 128 watt taps:

____at 128 watt each =

____watts

(E5 to E5)

70-VOLT SPEAKERS

70-volt speakers have a power tap on them or on their associated transformer. Add together all of the
70-volt speaker tap settings and enter that value:

____watts (A1 to A2)
____watts (E7 to E7)
