Section 2: Installation & Programming

21822666

2 - 5

PROCEDURES FOR LOADING DISCS

Load discs as follows:

1. Unlock and open the top door.

2. Pull the SERVICE button out to the SERVICE position (refer

to Figure 2-4). The SERVICE switch is located in the upper
right-hand corner of the cabinet.

3. Press the CANCEL/SCAN button (located on the CD changer

mechanism) to move the disc space to the left or right of the
transfer arm.

4. Slide the CD into the slot with the label to the right.

Note that disc positions in the molded CD magazine are identi-
fied by numbers at every other slot, with even numbered slots
labeled on one half of the magazine and odd numbered slots
labeled on the other half.

For example, on the even numbered half of the magazine, slots
00, 04, and 08 are labeled, and the slots in between – 02 and
06 – are not, as illustrated in Figure 2-5.

NOTE:

When loading the magazine, make sure the disc rests in the same numbered slot in
both the front and rear of the magazine.

Figure 2-5. Loading the Molded CD Magazine

Figure 2-4. Service Switch
