Rowe CD-100K User Manual
Page 48

Section 2: Installation & Programming
21822666
2 - 2 3
1000 w
atts
Amplifier
E1
E7
E1
E7
Speak
ers
Left Channel
Speak
ers
Right Channel
F
our 4 ohm speak
ers each r
ated at a minim
um of
300 w
atts each.
(Note:
Left channel is out of phase
,
plus + and min
us -, in hookup with respect to r
ight
channel)
EA
CH SPEAKER OUTPUT IS 250
W
A
TTS
DIAGRAM 1
1000 w
atts
Amplifier
E1
E7
E1
E7
Speak
ers
Left Channel
Speak
ers
Right Channel
Eight 8 ohm speak
ers each r
ated at a minim
um of
150 w
atts each.
(Note:
Left channel is out of phase
,
plus + and min
us -, in hookup with respect to r
ight channel)
EA
CH SPEAKER OUTPUT IS 125
W
A
TTS
DIAGRAM 2
