Section 2: Installation & Programming
21822666
2 - 1 3
Table 2-1. Extension Speaker Worksheet
Sheet 2
4-OHM SPEAKERS CONNECTED TO TRANSFORMER TAPS
Place the quantity of speakers in the blank under QTY and multiply the quantity times the power consumption (show
stereo speakers as 2 speakers). Place your results in the blank under TOTAL.
4-Ohm Stereo Speakers connected to transformer taps
QTY
Total
Connections
Speakers for the 1 watt taps:
____at 1 watt each =
____watts
(E1 to E2)
Speakers for the 4 watt taps:
____at 4 watts each =
____watts
(E1 to E3)
Speakers for the 16 watt taps:
____at 16 watts each =
____watts
(E1 to E4)
Speakers for the 36 watt taps:
____at 36 watts each =
____watts
(E3 to E5)
Speakers for the 49 watt taps:
____at 49 watts each =
____watts
(E2 to E5)
Speakers for the 64 watt taps:
____at 64 watts each =
____watts
(E1 to E5)
Speakers for the 100 watt taps:
____at 100 watts each =
____watts
(E3 to E6)
Speakers for the 121 watt taps:
____at 121 watts each =
____watts
(E2 to E6)
4-Ohm Mono Speakers connected to transformer taps
Speakers for the 4 watt taps:
____at 4 watts each =
____watts
(E2 to E2)
Speakers for the 16 watt taps:
____at 16 watts each =
____watts
(E3 to E3)
Speakers for the 64 watt taps:
____at 64 watts each =
____watts
(E4 to E4)
Speakers for the 256 watt taps:
____at 256 watts each =
____watts
(E5 to E5)
