Section 2: Installation & Programming

21822666

2-83

Example for programming a new message

When this example is complete, the display will read HELLO TOM as message number three.

A. Follow step AA to obtain MSG 1 EDT DEL VU.

B. Push key 3 to edit message three. Push POPULAR.

C. Push POPULAR to go to the edit screen.
D. Display should be blank except the cursor flashing at digit eight (see Table 2-6).

E. Push key 1 until the display shows H. Push POPULAR (cursor points to the next character).
F. Push key 1 until the display shows E. Push POPULAR.

G. Push key 1 until display shows L. Press POPULAR.
H. Push key 7. Display shows L. Press POPULAR.

I. Push key 7. Display shows L. Then push key 1 until the display shows O. Press POPULAR.

J. Push POPULAR. Display shows a “space”.

K. Push key 1 until display shows T. Push POPULAR.

L. Push key 7. Display shows T. Then push key 0 until display shows O. Push POPULAR.

M. Push key 7. Display shows O. Then push key 0 until display shows M. Push POPULAR.

N. Press the key 9 to exit and save the message.

1

2

3

4

5

6

7

8

9

10

11

12

13

14

15

16

A

M

S

G

1

E

D

T

D

E

L

V

U

B

M

S

G

3

E

D

T

D

E

L

V

U

C

__

D

H

__

E

H

E

__

F

H

E

L

__

G

H

E

L

L

__

H

H

E

L

L

O

__

I

H

E

L

L

O

__

J

H

E

L

L

O

T

__

K

E

L

L

O

T

O

__

L

L

L

O

T

O

M

__

M

M

S

G

3

E

D

T

D

E

L

V

U

Table 2-6. Example Message Program Sequence Display
