tasks in the RUNNING, READY, or WAITING state.

If the suspend request is made to a task in the SUS-

PENDED state, an error code is returned.

5. WAITING-SUSPENDED

If a suspend request is issued to a task currently in a WAITING state, the task goes to a WAITING-SUSPENDED
state. If a suspend request is issued to a task that has been placed into a WAITING state for a wait request by the
slp_tsk, wai_flg, wai_sem, rcv_mbx, snd_dtq, rcv_dtq, vsnd_dtq, vrcv_dtq, get_mpf, tslp_tsk, twai_flg, twai_sem,
trcv_mbx, tsnd_dtq, trcv_dtq, vtsnd_dtq, vtrcv_dtq or tget_mpf service call, the task goes to a WAIT-
ING-SUSPENDED state.

When the wait condition for a task in the WAITING-SUSPENDED state is cleared, that task goes into the SUS-
PENDED state. It is conceivable that the wait condition may be cleared, when any of the following conditions
occurs.

♦ The task wakes up upon wup_tsk, or iwup_tsk service call issuance.

♦ The task placed in the WAITING state by the dly_tsk or tslp_tsk service call wakes up after the

specified time elapse.

♦ The request of the task placed in the WAITING state by the wai_flg , wai_sem, rcv_mbx, snd_dtq,

rcv_dtq, vsnd_dtq, vrcv_dtq, get_mpf, tslp_tsk, twai_flg, twai_sem, trcv_mbx, tsnd_dtq, trcv_dtq,
vtsnd_dtq, vtrcv_dtq or tget_mpf service call is fulfilled.

♦ The WAITING state is forcibly cleared by the rel_wai or irel_wai service call

When the SUSPENDED state clear request by rsm_tsk or irsm_tsk is made to a task in the WAIT-
ING-SUSPENDED state, that task goes into the WAITING state. Since a task in the SUSPENDED state cannot
request to be placed in the WAITING state, status change from SUSPENDED to WAITING-SUSPENDED does
not possibly occur.

6. DORMANT

This state refers to the condition in which a task is registered in the MR100 system but not activated. This task
state prevails when either of the following two conditions occurs.

♦ The task is waiting to be activated.

♦ The task is normally terminated by ext_tsk service call or forcibly terminated by ter_tsk service

call.

If a forcible wait request is issued to a task currently in a wait state, the task goes to a WAITING-SUSPENDED state.
