- 156 -
5.10 Time Management Function (Cyclic Handler)
Specifications of the cyclic handler function of MR100 are listed in Table 5.19. The cyclic handler description languages in
item No. 4 are those specified in the GUI configurator. They are not output to a configuration file, nor are the MR100 ker-
nel concerned with them.
Table 5.19 Specifications of the Cyclic Handler Function
No. Item Content
1 Cyclic handler ID 1-255
2 Activation cycle 0-7fffffff[ms]
3 Activation phase 0-7fffffff[ms]
4 Extended information 32 bits
TA_HLNG: Handlers written in high-level language
TA_ASM: Handlers written in assembly language
TA_STA: Starts operation of cyclic handler
5 Cyclic handler attribute
TA_PHS: Saves activation phase
Table 5.20 List of Cyclic Handler Function Service Call
System State No. Service Call Function
T N E D U L
1 sta_cyc [S][B] O O O O
2 ista_cyc
Starts cyclic handler operation
O O O O
3 stp_cyc [S][B] O O O O
4 istp_cyc
Stops cyclic handler operation
O O O O
5 ref_cyc O O O O
6 iref_cyc
Reference cyclic handler status
O O O O
Notes:
•
[S]: Standard profile service calls
[B]: Basic profile service calls
•
Each sign within " System State " is a following meaning.
♦ T: Can be called from task context
♦ N: Can be called from non-task context
♦ E: Can be called from dispatch-enabled state
♦ D: Can be called from dispatch-disabled state
♦ U: Can be called from CPU-unlocked state
♦ L: Can be called from CPU-locked state
