255
Configuration File
xxx.cfg
Default
Configuration File
default.cfg
Template File
sys_ram.inc, mr100.inc
MR100 Version File
version
System Data Difinition File
sys_ram.inc, sys_rom.inc
Include File
mr100.inc
cfg100
Service call Definition File
kernel_sysint.h
Service call Definition File
kernel_sysint.h
ID Number Definition File
kernel_id.h
Figure 8.1 The operation of the Configurator
8.2.2 Setting Configurator Environment
Before executing the configurator, check to see if the environment variable "LIB100" is set correctly.
The configurator cannot be executed normally unless the following files are present in the directory indicated by the envi-
ronment variable "LIB100":
•
Default configuration file (default.cfg)
This file can be copied to the current directory for use. In this case, the file in the current directory is given priority.
•
System RAM area definition database file (sys_ram.inc)
•
mr100.inc template file (mr100.inc)
•
Section definition file(c_sec.inc or asm_sec.inc)
•
Startup file(crt0mr.a30 or start.a30)
•
MR100 version file(version)
•
Service call definition file(kernel_sysint.h)
