Using the RD-300GX As a Master Keyboard
When you have finished connecting the external MIDI device, match the keyboard’s
Transmit channel and the Receive channel for each of the external MIDI sound
generator’s Parts. Sounds is produced when the MIDI channels for the sending device
(the RD-300GX) and the receiving device (the external MIDI sound generator) are set to
the same MIDI channel.
fig.Q3-03p
1. Press the [EXTERNAL/INTERNAL] button so the “EXTERNAL” indicator is lit.
The External screen appears.
If the following screen doesn’t appear, hold down the [EXIT/SHIFT] button and press the [DEC]
button several times.
2. Press the ZONE SELECT button so the indicator of the button for the Zone you
wish to select is lit.
3. Use the [DEC] [INC] buttons to set the transmit channel for each Zone.
If you turn this “OFF,” MIDI data will not be transmitted for that Zone.
For instructions on setting each of the external MIDI sound generator’s Part’s Receive
channel, refer to the owner’s manual for each device.
When “Rec Mode” is set to ON in the Utility in Edit mode, the External screen as
shown above is not displayed. Set “Rec Mode” to OFF when setting the MIDI Transmit
channel (p. 78).
Setting the MIDI Transmit Channel (MIDI OUT Channel)
Part Parameter Settings Description
UPPER 1
Ch
(MIDI OUT Channel)
1–16, OFF
RD-300GX
performance data is
sent over a selected
channel.
UPPER 2
LOWER
NOTE
