Page 93
Replacing Consumables
81
4
D
Push the right and left lock levers
of the charger.
The locks release, and the charger
is lifted slightly.
E
Remove the charger.
F
Install a new charger into the
printer.
Insert the new charger into the
printer with the arrow of the
charger cleaner's lever facing to-
ward you. The charger locks auto-
matically.
Note
❒ Return the charger cleaner to
the left or print problems may
occur.
G
Holding the green inset grips of
the new photoconductor unit,
push the unit back to its original
position.
H
Close the front cover.
Confirm that the front cover closes
properly.
I
Turn on the printer’s power switch.
J
Press {
Menu
}.
The following message appears on
the panel display.
