Troubleshooting
78
4
B Remove the ozone filter from
inside the ventilator hole cover.
C Install a new ozone filter on
the ventilator hole cover.
D Return the ventilator hole cov-
er its original position.
D
Replace the two ozone filters in-
side the printer.
A Push the front cover release but-
ton and open the front cover.
B Grasping the ozone filter by its
tab, remove it from the printer.
C Insert a new ozone filter into
the printer.
Slide the filter into the stopper.
Two small thin plastic tabs of
the top of the filter should click
into place.
D Close the front cover.
Confirm that the front cover
close properly.
E
Turn on the printer’s power
switch.
Note
❒ After replace the fuser oil bottle,
it takes a few minutes until the
message clears.
Replacing the Waste Toner
Bottle
Replace the waste toner bottle when-
ever the following messages appear
on the panel display.
IPDL-C
Waste T Full
Waste Toner is
Full
TFWX070E
TFWX080E
TFWX310E
TFWX320E
