Ricoh AP306 - Manual (Page 133)

Specifications
121
6
❖ Power consumption:
❖ Noise emission *1
❖ Sound power level
❖ Sound pressure level *2
*1 The above measurements made in accordance with ISO 7779 are actual value.
*2 It is measured at the position of the operator.
❖ Dimensions:
❖ Simplex printer
Simplex printer Duplex printer
Standby (Maximum) 150 W or less
Printing (Maximum) 1,200 W or less
Printing (Average) 750 W or less
Energy Saver (Maximum) 45 W or less
Simplex printer
Mainframe only
Duplex printer
Mainframe only
During printing 65 dB (A)
Stand-by 43 dB (A)
Simplex printer
Mainframe only
Duplex printer
Mainframe only
During printing 57 dB (A)
Stand-by 33 dB (A)
Width Depth Height
Printer only 660 mm (26") 625 mm (24.6") 475 mm (18.7")
With one optional
paper feed unit
660 mm (26") 625 mm (24.6") 601 mm (23.7")
With two optional
paper feed units
660 mm (26") 625 mm (24.6") 727 mm (28.6")
