Troubleshooting
60
4
C
When the misfed paper is in the
main section of the photoconduc-
tor unit, turn the dial downward
then remove it.
Confirm that you do not leave any
misfed paper in the printer.
Note
❒ If it is difficult to turn the dial,
turn it slightly upward and then
try again.
D
Close the front cover.
When the Message "Remove
Misfeed From Output Tray"
Appears
Simplex printer
R CAUTION:
A
Open the paper exit cover.
Note
❒ When opening the paper exit
cover, be careful as it may be
hot.
B
Push the front cover release but-
ton and open the front cover.
C
Turn the dial downward, then re-
move the misfed paper in the
printer.
Note
❒ When removing misfed paper,
be careful not to touch the fus-
ing section because it could be
very hot.
When you can see the misfed
paper inside the printer
Note
❒ If it is difficult to turn the dial,
turn it slightly upward and then
try again.
• When removing misfed paper,
do not touch the fusing section
because it could be very hot.
TFWX220E
TFWX230E
TFWX080E
