Replacing Consumables
77
4
❒ Disposal can take place at our au-
thorized dealer or at appropriate
collection sites.
❒ Dispose of used ozone filters as
general burnable refuse.
A
Turn off the printer's power
switch.
B
Replace the oil bottle.
A Remove the green cap from the
new oil bottle.
Important
❒ Hold the clear cap while
turning the green cap. Do not
remove the clear cap.
B Open the fuser oil bottle cover
of the printer.
C Remove the used oil bottle
from the printer carefully.
D Insert the new oil bottle into
the oil bottle case.
E Close the fuser oil bottle cover.
Important
❒ The fuser oil bottle cover
should be kept closed.
C
Replace the ozone filter on the
rear of the printer.
A Remove the ventilator hole
cover.
❖ Simplex printer
❖ Duplex printer
TFWX031E
TFWX090E
TFWX100E
ZBGX050E
ZBGX060E
