Appendix | MFX and IFX types and parameters
E-80 Music Workstation
r
271
● EQ Mid Q (0.5, 1.0, 2.0, 4.0, 8.0)—Width of midrange
(larger values make the region narrower).
● EQ High Frequency (2000Hz, 4000Hz, 8000Hz)—Fre-
quency of the high-range EQ.
● EQ High Gain (-15dB~0~15dB)—Amount of high-range
boost/cut.
83. VIB-OD-Rotary
This effect combines an overdrive and a rotary with Vibrato/
Chorus. The vibrato effect cyclically modulates the pitch of
organ sounds (which is not the same as the Rotary effect).
The chorus effect mixes the normal sound of the organ with a
sound to which vibrato has been applied, adding richness and
spaciousness to the sound.
● Vibrato Chorus Switch (Off, On)—Turns the Vibrato Cho-
rus on/off.
● Vibrato Chorus Type (V-1, V-2, V-3, C-1, C-2, C-3)—
V-1, V-2, V-3: This applies vibrato (pitch modulation).
Increasing the value will produce a deeper effect.
C-1, C-2, C-3: This applies chorus to add depth and spa-
ciousness to the sound. Increasing the value will produce a
deeper effect.
● Vibrato Chorus Vintage (‘50, '60, '70)—Tonewheel sounds
of the 1950s, ‘60s and ‘70.
● Vibrato Chorus Level (0~127)—Level of the Vibrato Cho-
rus effect.
● Overdrive Switch (Off, On)—Turns the Overdrive on/off
● Overdrive Drive (0~127)—Degree of distortion
● Overdrive Level (0~127)—Sets the Overdrive output level.
● Rotary Switch (Off, On)—Turns the Rotary on/off.
● Rotary Speed (Slow, Fast)—Rotational speed of the rotat-
● Rotary Woofer Slow Speed (0.05~10.00Hz)—Low-speed
● Rotary Woofer Fast Speed (0.05~10.00Hz)—High-speed
● Rotary Woofer Acceleration (0~15)—Adjusts the time it
takes the rotor woofer to reach the newly selected speed
(“Fast” or “Slow”). Lower values correspond to slower tran-
sitions.
● Rotary Woofer Level (0~127)—Sets the woofer level.
● Rotary Tweeter Slow Speed (0.05~10.00Hz)—Low-speed
rotation speed of the tweeter.
● Rotary Tweeter Fast Speed (0.05~10.00Hz)—High-speed
rotation speed of the tweeter.
● Rotary Tweeter Acceleration (0~15)—Adjusts the time it
takes the rotor tweeter to reach the newly selected speed
(“Fast” or “Slow”). Lower values correspond to slower tran-
sitions.
● Rotary Tweeter Level (0~127)—Sets the tweeter level.
● Rotary Separation (0~127)—Spatial dispersion of the
sound.
● Rotary Level (0~127)—Sets the output level of the effect.
84. Center Canc
Removes the sounds that are localized at the center of the
stereo input. This is a convenient way to eliminate a vocal.
● L-R Balance (–50~0~50)—Volume balance of the L (left)
and R (right) channels for removing the sound.
● Range Low (16~15000Hz)—Lower frequency limit of the
band to be removed.
● Range High (16~15000Hz)—Upper frequency limit of the
band to be removed.
