184
MIDI Implementation
❍ Balance (Controller number 8)
status 2nd byte 3rd byte
BnH 08H vvH
n=MIDI channel number: 0H - FH (ch.1 - ch.16)
vv=Balance: 00H - 7FH (0 - 127)
❍ Panpot (Controller number 10)
status 2nd byte 3rd byte
BnH 0AH vvH
n=MIDI channel number: 0H - FH (ch.1 - ch.16)
vv=Panpot: 00H - 40H - 7FH (left - center - right)
* Adjust the stereo location over 128 steps, where 0 is far left, 64 is center, and 127 is far
right. However this is not received when the Pan parameter (PATCH/CONTROL/
RxSWITCH) is OFF.
❍ Expression (Controller number 11)
status 2nd byte 3rd byte
BnH 0BH vvH
n=MIDI channel number: 0H - FH (ch.1 - ch.16)
vv=Expression: 00H - 7FH (0 - 127)
* If the Volume parameter (SYSTEM/CONTROL/CONTROL SOURCE) is set to
VOL&EXP, the volume of the Part corresponding to the MIDI channel of the received
message will be adjusted. However this is not received if the Volume parameter
(PATCH/CONTROL/RxSWITCH) is OFF.
* In GM mode, the volume can always be controlled.
❍ Hold 1 (Controller number 64)
status 2nd byte 3rd byte
BnH 40H vvH
n=MIDI channel number: 0H - FH (ch.1 - ch.16)
vv=control value: 00H - 7FH (0 - 127) 0-63=OFF, 64-127=ON
* Not received when the Hold-1 RxSwitch parameter (PATCH/CONTROL/DAMPER) is
OFF.
❍ Portamento (Controller number 65)
status 2nd byte 3rd byte
BnH 41H vvH
n=MIDI channel number: 0H - FH (ch.1 - ch.16)
vv=control value: 00H - 7FH (0 - 127) 0-63=OFF, 64-127=ON
* The Sw parameter (PATCH/CONTROL/PORTAMENTO) will change.
❍ Sostenuto (Controller number 66)
status 2nd byte 3rd byte
BnH 42H vvH
n=MIDI channel number: 0H - FH (ch.1 - ch.16)
vv=control value: 00H - 7FH (0 - 127) 0-63=OFF, 64-127=ON
❍ Soft (Controller number 67)
status 2nd byte 3rd byte
BnH 43H vvH
n=MIDI channel number: 0H - FH (ch.1 - ch.16)
vv=control value: 00H - 7FH (0 - 127) 0-63=OFF, 64-127=ON
❍ Hold 2 (Controller number 69)
status 2nd byte 3rd byte
BnH 45H vvH
n=MIDI channel number: 0H - FH (ch.1 - ch.16)
vv=control value: 00H - 7FH (0 - 127)
* A hold movement isn't done.
❍ Sound Controller 2 (Controller number 71)
status 2nd byte 3rd byte
BnH 47H vvH
n=MIDI channel number: 0H - FH (ch.1 - ch.16)
vv=control value: 00H - 40H - 7FH (-128 - 0 - +126)
* The Res parameter (PATCH/TVF/FILTER) will change relatively.
❍ Sound Controller 3 (Controller number 72)
status 2nd byte 3rd byte
BnH 48H vvH
n=MIDI channel number: 0H - FH (ch.1 - ch.16)
vv=control value: 00H - 40H - 7FH (-128 - 0 - +126)
* The T2–4 parameter (PATCH/TVF/TVF ENVELOPE), The T2–4 parameter (PATCH/
TVA/TVA ENVELOPE) will change relatively.
❍ Sound Controller 4 (Controller number 73)
status 2nd byte 3rd byte
BnH 49H vvH
n=MIDI channel number: 0H - FH (ch.1 - ch.16)
vv=control value: 00H - 40H - 7FH (-128 - 0 - +126)
* The T1 parameter (PATCH/TVF/TVF ENVELOPE), The T1 parameter (PATCH/TVA/
TVA ENVELOPE) will change relatively.
❍ Sound Controller 5 (Controller number 74)
status 2nd byte 3rd byte
BnH 4AH vvH
n=MIDI channel number: 0H - FH (ch.1 - ch.16)
vv=control value: 00H - 40H - 7FH (-64 - 0 - +63)
* The Cut parameter (PATCH/TVF/FILTER) will change relatively.
❍ General Purpose Controller 5 (Controller number 80)
status 2nd byte 3rd byte
BnH 50H vvH
n=MIDI channel number: 0H - FH (ch.1 - ch.16)
vv=control value: 00H - 40H - 7FH (-128 - 0 - +126)
* The L1–3 parameter (PATCH/TVA/TVA ENVELOPE) of Tone 1 will change relatively.
❍ General Purpose Controller 6 (Controller number 81)
status 2nd byte 3rd byte
BnH 51H vvH
n=MIDI channel number: 0H - FH (ch.1 - ch.16)
vv=control value: 00H - 40H - 7FH (-128 - 0 - +126)
* The L1–3 parameter (PATCH/TVA/TVA ENVELOPE) of Tone 2 will change relatively.
❍ General Purpose Controller 7 (Controller number 82)
status 2nd byte 3rd byte
BnH 52H vvH
n=MIDI channel number: 0H - FH (ch.1 - ch.16)
vv=control value: 00H - 40H - 7FH (-128 - 0 - +126)
* The L1–3 parameter (PATCH/TVA/TVA ENVELOPE) of Tone 3 will change relatively.
❍ General Purpose Controller 8 (Controller number 83)
status 2nd byte 3rd byte
BnH 53H vvH
n=MIDI channel number: 0H - FH (ch.1 - ch.16)
vv=control value: 00H - 40H - 7FH (-128 - 0 - +126)
* The L1–3 parameter (PATCH/TVA/TVA ENVELOPE) of Tone 4 will change relatively.
❍ Portamento Control (Controller number 84)
status 2nd byte 3rd byte
BnH 54H kkH
n=MIDI channel number: 0H - FH (ch.1 - ch.16)
kk=source note number: 00H - 7FH (0 - 127)
* A Note On message received immediately after a Portamento control will be sounded
with the pitch changing smoothly from the source note number. If a voice is already
sounding at the same note number as the source note number, that voice will change
pitch to the pitch of the newly received Note On, and continue sounding (i.e., will be
played legato).
* The speed of the pitch change caused by Portamento is determined by the Time
parameter (PATCH/CONTROL/PORTAMENTO) value.
