Chapter 4
Technical Specifications
RUGGEDCOM RX1512
Installation Guide
34
Operating Environment
3. F51 transceivers are rated for -40°C to +85°C.
Section 4.5
Operating Environment
Table: Operating Environment
Parameter
Range
Comments
Ambient Operating Temperature
-40°C to 85°C
Ambient Temperature as measured from a 30cm
radius surrounding the center of the enclosure.
Section 4.6
RuggedAPE™ Specifications
Table: RuggedAPE™ Specifications
Feature
APE1402
APE1402W7
APE1404
APE1404W7
APE1404CPK
Processor
Intel Atom E660 1.3 GHz, 512KB L2 Cache
Intel Atom E660T 1.3 GHz, 512KB L2 Cache
RAM
2 GB DDR2, 800 MHz, 32-bit
Disk
8 GB SATA, solid state
16 GB SATA, solid state
Networking
Realtek RTL8111, RJ45 Gigabit Ethernet interface
USB
2 x USB 2.0, maximum combined USB device power consumption 500 mA at 5 V
Video
Intel 4108 Grpahics Processor, DVI-D
LED Indications
Power and Disk
Contols
Momentary contact reset button
Temperature Range
-40C to 70C
Power Requirements 12W with no USB load, 14.5W with full USB load
Software Platform
Debian Linux®
Windows®
Embedded Standard
7
Debian Linux®
Windows®
Embedded Standard
7
Check Point GAiA™
OS
Section 4.7
Mechanical Specifications
Table: Mechanical Specifications
Parameter
Value
Comments
Dimensions
4.83 Ч 4.40 Ч 7.00 REF (6.86) inches
122.68 Ч 111.76 Ч 177.80 REF (174.24) mm
(Height × Width × Depth)
Weight
Approximately 5 lbs (2.3 kg)
Weight dependent on module selection.
