RUGGEDCOM RX1512
Installation Guide
Chapter 4
Technical Specifications
Gigabit Ethernet (1Gbps) Optical Specifications 33
SFP Fast Ethernet Transceivers
Table: SFP Fast Ethernet Transceivers
Order
Code
Mode
Connector
Type
Cable
Type
(μm)
Tx λ
(typ.)
(nm)
Tx min
(dBm)
Tx max
(dBm)
Rx
Sensitivity
(dBm)
Rx
Saturation
(dBm)
Distance
(typ.)
(km)
Power
Budget
(dB)
62.5/125 -20 11
FX51 MM LC
50/125
1310
-23.5
-14 -31 -14 2
7.5
FX52 SM LC 9/125 1300 -15 -8 -31 -8 20 16
FX53 SM LC 9/125 1300 -5 0 -34 0 50 29
FX54 SM LC 9/125 1550 -5 0 -34 -10 90 29
Section 4.4.2
Gigabit Ethernet (1Gbps) Optical Specifications
Fixed Gigabit Transceivers
Table: Fixed Gigabit Transceivers
Order
Code
Mode
Connector
Type
Cable
Type
(μm)
Tx λ
(typ.)
(nm)
Tx min
(dBm)
Tx max
(dBm)
Rx
Sensitivity
(dBm)
Rx
Saturation
(dBm)
Distance
(typ.)
(km)
Power
Budget
(dB)
FG01 MM LC 50/125 850 -9 -2.5 -20 0 0.5 11
FG02 SM SC 9/125 1310 -10 -3 -20 -3 10 10
FG03 SM LC 9/125 1310 -9.5 -3 -21 -3 10 11.5
FG04 SM SC 9/125 1310 -5 0 -20 -3 25 15
FG05 SM LC 9/125 1310 -7 -3 -24 -3 25 17
SFP Gigabit Transceivers
Table: SFP Gigabit Transceivers
Order
Code
Mode
Connector
Type
Cable
Type
(μm)
Tx λ
(typ.)
(nm)
Tx min
(dBm)
Tx max
(dBm)
Rx
Sensitivity
(dBm)
Rx
Saturation
(dBm)
Distance
(typ.)
(km)
Power
Budget
(dB)
50/125 0.5
FG51 MM LC
62.5/125
850 -9 -2.5 -20 0
0.3
11
FG52 SM LC 9/125 1310 -9.5 -3 -19 -3 10 9.5
FG53 SM LC 9/125 1310 -7 -3 -23 -3 25 16
FG54 SM LC 9/125 1550 0 5 -23 -3 70 23
Notes:
1. Maximum segment length is greatly dependent on factors such as fiber quality, and the number of patches
and splices. Please consult RuggedCom sales associates when determining maximum segment distances.
2. All optical power numbers are listed as dBm averages.
