Chapter 4
Technical Specifications
RUGGEDCOM RX1512
Installation Guide
32 Fiber Ethernet Port Specifications
Section 4.4
Fiber Ethernet Port Specifications
The following sections detail fiber optic specifications for ports that can be ordered with the modules on a
RUGGEDCOM RX1512. The user determines the type of optics at time of ordering, and can determine the
modules installed on a particular unit by reading the factory data file via the RX1512 user interface. Section 4.4.1,
“Fast Ethernet (100Mbps) Optical Specifications” and Section 4.4.2, “Gigabit Ethernet (1Gbps) Optical
Specifications” list the specifications of the optical transceivers used in the fiber Ethernet modules available for
the RX1512. The specifications are organized by order code. Module order codes are contained within each
unit when it is assembled and configured at the factory. Consult the RuggedCom RX1512 User Guide for help in
obtaining the factory configuration data.
Section 4.4.1
Fast Ethernet (100Mbps) Optical Specifications
Fixed Fast Ethernet Transceivers
Table: Fast Ethernet (100Mbps) Optical Specifications
Order
Code
Mode
Connector
Type
Cable
Type
(μm)
Tx λ
(typ.)
(nm)
Tx min.
(dBm)
Tx max.
(dBm)
Rx
Sensitivity
(dBm)
Rx
Saturation
(dBm)
Distance
(typ.)
(km)
Power
Budget
(dB)
62.5/125 -19 12
FX01 MM ST
50/125
1300
-22.5
-14 -31 -14 2
8.5
62.5/125 -19 12
FX02 MM SC
50/125
1300
-22.5
-14 -31 -14 2
8.5
MTRJ 62.5/125 -19 12
FX11 and
4FX11
MM
LC 50/125
1300
-22.5
-14 -31 -14 2
8.5
62.5/125 -19 12
FX03 and
4FX03
MM MTRJ
50/125
1300
-22.5
-14 -31 -14 2
8.5
FX04 SM ST 9/125 1300 -15 -8 -32 -3 20 17
FX05 SM SC 9/125 1300 -15 -8 -31 -7 20 16
FX06 and
4FX06
SM LC 9/125 1300 -15 -8 -34 -7 20 19
FX07 SM SC 9/125 1300 -5 0 -34 -3 50 29
FX08 and
4FX08
SM LC 9/125 1300 -5 0 -35 3 50 30
FX09 SM SC 9/125 1300 0 5 -37 0 90 37
FX10 and
4FX10
SM LC 9/125 1300 0 5 -37 0 90 37
