Ricoh MIB-II - Manual (Page 25)

Operating Instructions Administrator Reference
25
FFFF
Select the port you want to use.
• SmartNetMonitor
• Standard TCP/IP Port
• LPR Port
SmartNetMonitor
A Click [ Create a new port: ] .
B Select [ SmartNetMonitor ] , and then click [ Next > ] .
C Select a printer you want to use.
❖ ❖ ❖ ❖ TCP/IP
A Click [ TCP/IP ] , and then click [ Search ] .
Available printers will be listed.
B Click the printer you want to use, and then click [ OK ] .
Note
❒ Printers that respond to an IP broadcast from the computer will be displayed. To print to a
printer not listed here, click [
Specify Address ], and then type the IP address or host name.
❒ You cannot add an address partially similar to that already used. For example, when
“192.168.0.2” is already used, “192.168.0.2xx” cannot be used. Similarly, when
“192.168.0.20” is already used, “192.168.0.2” cannot be used.
❖ ❖ ❖ ❖ NetBEUI
A Click [ NetBEUI ] , and then click [ Search ] .
A list of printers that can be used by the NetBEUI protocol appears.
