Operational Specifications
3.1.6 Extension Connectors (J9-J13)
Rev.1.0 Dec 15, 2006
3-13
REJ10J0917-0100
3
Table3.1.11 lists pin assignments of extension connectors (J12, J13).
Table3.1.11 Pin Assignments of Extension Connectors (J12, J13)
Pin
J13
Pin
J12
Signal Name
Other connection
1 -
+5V -
2 -
+5V -
3 -
PA9/WAIT
_________
/TCLKD/TXD2
-
4 -
NC -
5 -
NC -
6 -
NC -
7 -
NC -
8 -
NC -
9 -
NC -
10 -
NC -
11 -
NC -
12 -
NC -
13 -
NC -
14 -
NC -
15 -
NC -
16 -
NC -
17 -
NC -
18 -
NC -
19 -
NC -
20 -
GND
-
21
1
NC -
22
2
NC -
23
3
PA6/RD
_____
/UBCTRG
_______________
/TCLKA/POE4
_________
-
24
4
PD15/D15/AUDSYNC
________________
H-UDI Connector(J1)
25
5
PD14/D14/AUDCK H-UDI
Connector(J1)
26
6
PD13/D13/AUDMD -
27
7
PD12/D12/AUDRST
______________
-
28
8
NC (PD11/D11/AUDATA3 when R55 mounted)
H-UDI Connector(J1) when R55 mounted
29
9
NC (PD10/D10/AUDATA2 when R56 mounted)
H-UDI Connector(J1) when R56 mounted
30
10
NC (PD9/D9/AUDATA1 when R57 mounted)
H-UDI Connector(J1) when R57 mounted
31
11
NC (PD8/D8/SCK2/AUDATA0 when R58 mounted)
H-UDI Connector(J1) when R58 mounted
32
12
PD7/D7/IRQ3/TXD2
User I/O Connector(J7)
33
13
PD6/D6/IRQ2/RXD2
User I/O Connector(J7)
34
14
PD5/D5/IRQ1/SCK1
User I/O Connector(J7)
35
15
PD4/D4/IRQ0/TXD1 -
36
16
PD3/D3/RXD1 -
37
17
PD2/D2/SCK0 -
38
18
PD1/D1/TXD0 -
39
19
PD0/D0/RXD0 -
40
20
GND
-
