Page 30
Operational Specifications
3.1 M3A-HS49 Connectors Outline
3
3.1 M3A-HS49 Connectors Outline
Figure3.1.1 shows the M3A-HS49 Connector assignments.
< Top view of the solder side >
J11
J10
J9
J6
J12
J13
J7,J8
J14
J3
J5
J4
J2
J1
Figure3.1.1 M3A-HS49 Connector Assignments
Rev.1.0 Dec 15, 2006
3-2
REJ10J0917-0100
