Operational Specifications

3.1.5 User I/O Connector (J6-J8)

3

Table3.1.7 lists pin assignments of User I/O Connector (J7).

Table3.1.7 Pin Assignments of User I/O Connector (J7)

Pin

Signal Name

Other connection

1

PD5/D5/IRQ1/SCK1

Extension Connector(J12, J13)

2

PD6/D6/IRQ2/RXD2

Extension Connector(J12, J13)

3

PD7/D7/IRQ3/TXD2

Extension Connector(J12, J13)

Table3.1.8 lists pin assignments of User I/O Connector (J8).

Table3.1.8 Pin Assignments of User I/O Connector (J8)

Pin

Signal Name

Other connection

1

PF0/AN0 -

2

PF6/AN6 -

3

PF11/AN11 -


Rev.1.0 Dec 15, 2006

3-9

REJ10J0917-0100
