Operational Specifications
3.1.6 Extension Connectors (J9-J13)
Rev.1.0 Dec 15, 2006
3-11
REJ10J0917-0100
3
Table3.1.9 lists pin assignments of extension connectors (J9,J10).
Table3.1.9 Pin Assignments of Extension Connectors (J9, J10)
Pin
J10
Pin
J9
Signal Name
Other connection
1 -
+5V -
2 -
+5V -
3 -
WDTOVF
_______________
-
4 -
NC -
5 -
NC -
6 -
NC -
7 -
NC -
8 -
NC -
9 -
NC -
10 -
PB5/A19/IRQ3/POE5
_________
/TIC5U
User I/O Connector(J6)
11 -
PB4/A18/IRQ2/POE4
_________
/TIC5US -
12 -
PB3/A17/IRQ1/POE1
_________
/TIC5V
User I/O Connector(J6)
13 -
PB2/A16/IRQ0/POE0
_________
/TIC5VS
IRQ0 switch(SW6), LED8
14 -
PE8/A15/TIOC3A -
15 -
PE7/A14/TIOC2B -
16 -
PE6/A13/TIOC2A/SCK1 -
17 -
PE5/A12/TIOC1B/TXD1 -
18 -
PE4/A11/TIOC1A/RXD1 -
19 -
PA14/A10/RXD1 -
20 -
GND -
21
1
NC -
22
2
NC -
23
3
PA15/CK/TXD1 -
24
4
PA13/A9/SCK1 -
25
5
PA12/A8/SCK0 -
26
6
PA11/A7/TXD0/ADTRG
_____________
-
27
7
PA10/A6/RXD0 -
28
8
PA5/A5/IRQ3/SCK1 -
29
9
PA4/A4/IRQ2/TXD1 Serial
port select Jumper(JP3)
30
10
PA3/A3/IRQ1/RXD1 Serial
port select Jumper(JP4)
31
11
PA2/A2/IRQ0/POE2
_________
/SCK0 -
32
12
PA1/A1/POE1
_________
/TXD0 -
33
13
PA0/A0/POE0
_________
/RXD0 -
34
14
PE10/CS0
_______
/TIOC3C -
35
15
NC -
36
16
NC -
37
17
NC -
38
18
NC -
39
19
RES
_______
Reset Module
40
20
GND -
