NTI UNIMUX SERIES USB KVM SWITCH
2
MATERIALS
Materials supplied with this kit :
•
NTI UNIMUX-USBV-xO (x=2,4,8,16, or 32 ports) USB KVM Switch
• 110VAC or 220VAC at 50 or 60Hz-5VDC/2.0A AC Adapter
•
Line cord, country specific
•
Rack mount kit (4 and 8 port models only)
•
CD with pdf file of this manual
Materials Not supplied but REQUIRED:
•
A USBVEXT-xx-MM cable for each USB CPU being connected to the switch must be used for monitor, keyboard and mouse
interface.
•
An SA-xx-MM cable with 3.5mm stereo plug on each end for each audio source to be connected (models with audio support
only)
SA-xx-MM cables are available from NTI in 3,6,10, 15, 25, 35, 50 and 100 foot lengths
where:
xx is the length of the cable in feet
MM indicates male-to-male connector
Cables can be purchased from Network Technologies Inc by calling (800) 742-8324 (800-RGB-TECH) in the US and Canada or
(330) 562-7070 (worldwide).
DEFINITIONS
•
USB Composite
Device
A USB device that contains multiple endpoints each representing input devices that cannot be separated
(i.e. a keyboard with a built-in mouse)
•
USB Hub A USB device that allows one or more USB input devices to plug in to the USB. The hub has exactly one
upstream port with one or more downstream ports which input devices connect to
•
CPU Enclosure that contains the operating system and processor (i.e. Sun with SPARCstation5, Windows 95
with Pentium II)
•
Input Device Keyboard or Mouse
•
System One or more CPUs connected to one or more switches controlled by one or more input devices
