NTI UNIMUX SERIES USB KVM SWITCH
21
Change Settings
To enter the Change Settings menu (see Fig. 20) press <
Ctrl
>+<
T
> from the Command Mode menu.
The list below describes the Change Settings menu functions available from the keyboard:
Function:
Keystroke:
Go to Broadcast Mode Configuration
Go to Scan Mode Configuration
Go to Language Selection Menu
(Option only available if the
administrator is logged in)
Change the scan dwell time period
Configure ports for MAC or non-
MAC CPUs (Administrator only)
Enable/Disable right mouse button
click emulation
Exit from Change Settings
Return to Command Mode
Figure 20- Change Settings menu
When the
Settings menu. The user can introduce a new value for scan dwell time and press
between 002 and 255 (seconds) is acceptable.
Select Ports For Broadcast
To Select Ports For Broadcasting, press <
B
> from the Change Settings menu (see Fig. 20).
The Select Ports For Broadcast menu (see Fig. 21) enables the user to select specific ports to be active in Broadcast Mode. Only
the selected ports will receive keyboard messages in Broadcast Mode.
A checklist with all the port numbers will be displayed in the window.
•
unchecked box = the corresponding port is
not
in the
broadcast list
•
checked box = the corresponding port
is
in the
broadcast list
The user can toggle the state of the selected check box by
pressing
•
press <
S
> to check all of the ports
•
press <
C
> to uncheck all of the ports
The selected port is highlighted with a green bar. To select another
port, the user can use the arrow keys or mouse movement. The
name of the selected port is displayed at the bottom left of the
menu.
When <
Esc
> is pressed the display will return to the Change
Settings menu. The broadcast selection list is automatically saved.
Figure 21- Select ports for broadcasting
Esc
T
L
S
B
M
R
