National Instruments SCXI-1121 User Manual
Page 138
Appendix E
SCXI-1121 Cabling
E-16
www.natinst.com
39
No Connect
Solder pad
40
No Connect
Solder pad
41
No Connect
Solder pad
42
No Connect
Solder pad
43
RSVD
Solder pad
44
No Connect
Solder pad
45
No Connect
Solder pad
46
No Connect
Solder pad
47
No Connect
Solder pad
48
No Connect
Solder pad
49
No Connect
Solder pad
50
No Connect
Solder pad
Table E-4. SCXI-1343 Pin Connections (Continued)
Rear Signal
Connector Pin
SCXI-1121 Use
Connection Type
