Appendix E SCXI-1121 Cabling
© National Instruments Corporation E-15 SCXI-1121 User Manual
12 MCH4– Screw terminal
13 No Connect Screw terminal
14 No Connect Screw terminal
15 No Connect Screw terminal
16 No Connect Screw terminal
17 No Connect Screw terminal
18 No Connect Screw terminal
19 OUTREF Screw terminal
20 No Connect Solder pad
21 No Connect Solder pad
22 No Connect Solder pad
23 No Connect Solder pad
24, 33 DIG GND Solder pad
26 SERDATOUT Solder pad
27 DAQD*/A Solder pad
28 No Connect Solder pad
29 SLOT0SEL* Solder pad
30 No Connect Solder pad
31 No Connect Solder pad
32 No Connect Solder pad
33 No Connect Solder pad
34-35 No Connect Solder pad
36 SCANCLK Solder pad
37 SERCLK Solder pad
38 No Connect Solder pad
Table E-4. SCXI-1343 Pin Connections (Continued)
Rear Signal
Connector Pin SCXI-1121 Use Connection Type
