Appendix E SCXI-1121 Cabling
© National Instruments Corporation E-7 SCXI-1121 User Manual
Table E-3. SCXI-1342 Pin Translations
PC-LPM-16 Pin PC-LPM-16 Signal Rear Signal Connector Pin SCXI-1121 Use
1-2 AIGND 1-2 AOGND
3 ACH0 3 MCH0+
4 ACH8 4 MCH0–
5 ACH1 5 MCH1+
6 ACH9 6 MCH1-
7 ACH2 7 MCH2+
8 ACH10 8 MCH2–
9 ACH3 9 MCH3+
10 ACH11 10 MCH3–
11 ACH4 11 MCH4+
12 ACH12 12 MCH4–
13 ACH5 13 No Connect
14 ACH13 14 No Connect
15 ACH6 15 No Connect
16 ACH14 16 No Connect
17 ACH7 17 No Connect
18 ACH15 18 No Connect
19, 50 DGND 24, 33 DIG GND
28 DIN6 26 SERDATOUT
29 DIN7 28 No Connect
34 DOUT4 25 SERDATIN
35 DOUT5 27 DAQD*/A
36 DOUT6 29 SLOT0SEL*
37 DOUT7 37 SERCLK
46 OUT2 46 No Connect
49 +5 V 34-35 No Connect
