background image

Appendix E

SCXI-1121 Cabling

© National Instruments Corporation

E-5

SCXI-1121 User Manual

jumper W1. Table E-2 lists the SCXI-1341 and SCXI-1344 pin
translations.

Note

If you are using the Lab-PC+, configure the board for single-ended inputs.

Table E-2. SCXI-1341 and SCXI-1344 Pin Translations

Lab Board Pin

Lab Board Signal

SCXI-1121 Pin

SCXI-1121 Signal

1

ACH0

3

MCH0+

2

ACH1

5

MCH1+

3

ACH2

7

MCH2+

4

ACH3

9

MCH3+

5

ACH4

11

MCH4+

6

ACH5

13

No Connect

7

ACH6

15

No Connect

8

ACH7

17

No Connect

9

AIGND

1-2

AOGND

10

DAC0OUT

20

No Connect

11

AOGND

23

No Connect

12

DAC1OUT

21

No Connect

13, 50

DGND

24, 33

DIG GND

26

PB4

25

SERDATIN

27

PB5

27

DAQD*/A

28

PB6

29

SLOT0SEL*

29

PB7

37

SERCLK

31

PC1

26

SERDATOUT

32

PC2

28

No Connect

40

EXTCONV*

36

SCANCLK

43

OUTB1

46

No Connect

49

+5 V

34-35

No Connect
