NEC PX-42XM4A - Manual (Page 42)

En-41
Dots ן lines
1024 ן 768
1280 ן 1024
768 ן 576
640 ן 480
1152 ן 864
1400 ן 1050
Vertical
frequency
(Hz)
60.0
60.0
50.0
59.9
60.0
72.0
60.0
75.0
85.0
Horizontal
frequency
(kHz)
49.7
63.9
31.4
31.5
53.7
64.9
65.3
82.3
93.9
NORMAL
(4:3)
YES
YES* 4
YES* 7
YES* 7
YES
YES
YES
YES
YES
FULL
(16:9)
YES* 3
YES
YES* 7
YES* 7
YES
YES
YES
YES
YES
RGB
select* 5
– –
– –
– –
640 ן 480
1152 ן 864
– –
– –
– –
– –
Horizontal
– –
– –
NEG
NEG
POS
POS
NEG
NEG
NEG
Signal Type
Vertical
– –
– –
NEG
NEG
NEG
NEG
POS
POS
POS
Sync Polarity Presence
Horizontal
– –
– –
YES
YES
YES
YES
YES
YES
YES
Vertical
– –
– –
YES
YES
YES
YES
YES
YES
YES
Model
DVI
YES
YES
NO
NO
YES
YES
YES
YES
NO
Memory
62
29
31
32
84
85
65
71
72
Work Station
(SGI)
*1 Only when using a graphic accelerator board that is capable of displaying 852
ן480.
*2 Display only 640 lines with the screen center of the vertical orientation located at the center.
*3 The picture is displayed in the original resolution. The picture will be compressed for other signals.
*4 Aspect ratio is 5:4. This signal is converted to a 720 dots
ן768 lines signal.
*5 Normally the RGB select mode suite for the input signals is set automatically. If the picture is not displayed properly, set the
RGB mode prepared for the input signals listed in the table above.
*6 To connect the monitor to Macintosh computer, use the monitor adapter (D-Sub 15-pin) to your computer's video port.
*7 Other screen modes (ZOOM and STADIUM) are available as well.
*8 When viewing a moving picture at a vertical frequency greater than 65Hz, the picture may sometimes be unstable (jumpy).
If this occurs, please set the refresh rate of the external equipment to 60Hz.
*9 CVT standard compliant.
NOTE:
• While the input signals comply with the resolution listed in the table above, you may have to adjust the position and size of the picture or
the fine picture because of errors in synchronization of your computer.
• This monitor has a resolution of 1024 dots
ן768 lines. It is recommended that the input signal should be XGA, wide XGA, or equivalent.
• With digital input some signals are not accepted.
• The sync may be disturbed when a nonstandard signal other than the aforementioned is input.
• If you are connecting a composite sync signal, use the HD terminal.
What is HDCP/HDCP technology?
HDCP is an acronym for High-bandwidth Digital Content Protection. High bandwidth Digital Content Protection (HDCP) is a system for
preventing illegal copying of video data sent over a Digital Visual Interface (DVI).
If you are unable to view material via the DVI input, this does not necessarily mean the PDP is not functioning properly. With the implementation
of HDCP, there may be cases in which certain content is protected with HDCP and might not be displayed due to the decision/intention of the
HDCP community (Digital Content Protection, LLC).
