Telephone features, Installing enterprise edge telephones, Chapter 14 – Nortel Networks Enterprise Edge Feature Programming Telephone User Manual
Page 107: Telephone features 107, Installing enterprise edge telephones 107
P0908510 Issue 01
Enterprise Edge Feature Programming Telephone Guide
Telephone features
Installing Enterprise Edge telephones
If you are connecting an Enterprise Edge telephone for the first time, refer to the
following illustrations as a guide.
Installing an Enterprise Edge telephone
14
Connect to
jack wired from
distribution block
Connect to
receiver
