Reference Manual for the ADSL Modem Router DG834 v3
Virtual Private Networking (Advanced Feature) 6-21
v1.1, October 2006
Set the LAN IPs on each DG834 v3 to different subnets and configure each properly for the
Internet. The examples below assume the following settings:
Table 6-1. VPN Tunnel Configuration Worksheet
Connection Name: GtoG
Pre-Shared Key: 12345678
Secure Association -- Main Mode or Manual Keys: Main
Perfect Forward Secrecy -- Enabled or Disabled: Disabled
Encryption Protocol -- DES or 3DES: 3DES
Authentication Protocol -- MD5 or SHA-1: SHA-1
Diffie-Hellman (DH) Group -- Group 1 or Group 2: Group 2
Key Life in seconds: 28800 (8 hours)
IKE Life Time in seconds: 3600 (1 hour)
VPN Endpoint Local IPSec ID LAN IP Address Subnet Mask
FQDN or Gateway IP
(WAN IP Address)
DG834 v3_A GW_A 192.168.0.1 255.255.255.0 14.15.16.17
DG834 v3_B GW_B 192.168.3.1 255.255.255.0 22.23.24.25
Note: The LAN IP address ranges of each VPN endpoint must be different. The
connection will fail if both are using the NETGEAR default address range of
192.168.0.x.
