Reference Manual for the ADSL Modem Router DG834 v3

6-12

Virtual Private Networking (Advanced Feature)

v1.1, October 2006

b. From the Edit menu of the Security Policy Editor, click Add, then Connection. A “New

Connection” listing appears in the list of policies. Rename the “New Connection” so that it
matches the Connection Name you entered in the VPN Settings of the DG834 v3 on LAN
A.

Note: In this example, the Connection Name used on the client side of the VPN

tunnel is toDG834 and it does not have to match the RoadWarrior
Connection Name used on the gateway side of the VPN tunnel (see

Figure 6-5

) because Connection Names are arbitrary to how the VPN

tunnel functions.

Tip: Choose Connection Names that make sense to the people using and

administrating the VPN.

Figure 6-9
