Reference Manual for the ADSL Modem Router DG834 v3

6-6

Virtual Private Networking (Advanced Feature)

v1.1, October 2006

How to Set Up a Client-to-Gateway VPN Configuration

Setting up a VPN between a remote PC running the NETGEAR ProSafe VPN Client and a
network gateway (see

Figure 6-3

) involves the following two steps:

“Step 1: Configuring the Client-to-Gateway VPN Tunnel on the DG834 v3” on page 6-6

uses

the VPN Wizard to configure the VPN tunnel between the remote PC and network gateway.

“Step 2: Configuring the NETGEAR ProSafe VPN Client on the Remote PC” on page 6-11

configures the NETGEAR ProSafe VPN Client endpoint.

Step 1: Configuring the Client-to-Gateway VPN Tunnel on the
DG834 v3

The worksheet below identifies the parameters used in the following procedure. A blank
worksheet is at

“Planning a VPN” on page 6-3

.

Figure 6-3

Note: This section uses the VPN Wizard to set up the VPN tunnel using the VPNC

default parameters listed in

Table 6-2 on page 6-4

. If you have special requirements

not covered by these VPNC-recommended parameters, refer to

“How to Set Up

VPN Tunnels in Special Circumstances” on page 6-36

to set up the VPN tunnel.

192.168.3.1

VPN Tunnel

DG834

22.23.24.25

PC
(Running NETGEAR
ProSafe VPN Client)

PCs

0.0.0.0
