Reference Manual for the ADSL Modem Router DG834 v3

Virtual Private Networking (Advanced Feature)

6-27

v1.1, October 2006

b. Click on VPN Status (

Figure 6-30

) to get the Current VPN Tunnels (SAs) screen

(

Figure 6-29

). Click on Connect for the VPN tunnel you want to activate.

c.

Look at the VPN Status/Log screen (

Figure 6-28

) to verify that the tunnel is connected.

VPN Tunnel Control

Activating a VPN Tunnel

There are three ways to activate a VPN tunnel:

Use the VPN Status page.

Activate the VPN tunnel by pinging the remote endpoint.

Start using the VPN tunnel.

Figure 6-29

Note: Refer to

“Using Auto Policy to Configure VPN Tunnels” on page 6-36

to enable

the IKE keepalive capability on an existing VPN tunnel.
