55
Installation
ADSL WAN module replacement
The following sections describe how to replace the ADSL WAN module in a Business Services
Gateway 12-port (BSG12aw).
ADSL WAN module replacement navigation
• “Saving the running configuration to Flash using the WebUI” on page 55
• “Saving the running configuration to Flash using the CLI” on page 56
• “Replacing the ADSL WAN module” on page 56
• “Verifying the ADSL WAN module status” on page 57
Prerequisites to ADSL WAN module replacement
• If the system is still operating, perform the procedure “Shutting down the BSG8ew/12ew/
aw/tw” on page 63 .
• Obtain an ADSL WAN Replacement Module (NT5S21ZCE6) for the BSG12aw from
Nortel.
• Ensure you have the following items available:
— an antistatic wrist grounding strap
— a Phillips screwdriver
— grounding source
Saving the running configuration to Flash using the WebUI
Use this procedure to save the running configuration using the WebUI.
Procedure steps
Step Action
1 From the BSG12aw logon page, log on using the user ID and password.
2 From the left-hand navigation panel, select Administration, Configuration
File, Save.
3 Click Apply.
End
Caution: Risk of equipment damage
You must wear an antistatic grounding strap at all times when handling
electronic components. Failure to do so can result in damage to the equipment.
