Page 29
LED functionality 29
Installation
BSG8ew FXS and FXO port LEDs
BSG12ew/aw/tw FXS and FXO port LEDs
WAN port LEDs
The BSG8ew has two LEDs for the WAN port. For more information about the LEDs, see
“BSG8ew FE WAN interface LEDs” on page 30
“BSG12ew/aw/tw WAN interface LEDs” on
and the following tables.
LED
Status
Description
Green
Solid green
Off-hook.
Green
Flashing
Call ID generation and ringing.
Green
Off
On-hook.
FXO port LED
FXS port LEDs
No FXS port LEDs
No FXO port
