Page 58: Transfer characteristics
© National Instruments Corporation
A-1
A
Specifications
This appendix lists the specifications for the SCXI-1503 modules.
These specifications are typical at 25
°C unless otherwise noted.
Analog Input
Input Characteristics
Number of channels ............................... 16 differential
Input coupling ........................................ DC
Input signal ranges ................................. ±100 mV (gain = 100) or
±10 V (gain = 1)
Input overvoltage protection
Powered on ..................................... ±42 VDC
Powered off..................................... ±25 V
Inputs protected............................... AI<0..15>
CJ sensor input protection............... ±15 VDC powered on or off
Transfer Characteristics
Nonlinearity ........................................... 0.005% FSR
Input offset error (RTI)
Gain = 1
Calibrated
1
.............................. ±650
μV max
±250
μV typ
With autozero enabled
2
........... ±300
μV max
±150
μV typ
1
Assumes 1,000 point average, 25
°C ±10 °C over one year.
2
Assumes 1,000 point average, ±1
°C of autozero temperature.
