Acquiring, Analyzing, and Presenting
After configuring the task and channels, you can start the acquisition, read
measurements, analyze the data returned, and display it according to the
needs of your application. Typical methods of analysis include digital
filtering, averaging data, performing harmonic analysis, applying a custom
scale, or adjusting measurements mathematically.
NI provides powerful analysis toolsets for each NI ADE to help you
perform advanced analysis on the data without requiring you to have a
programming background. After you acquire the data and perform any
required analysis, it is useful to display the data in a graphical form or log
it to a file. NI ADEs provide easy-to-use tools for graphical display, such as
Table 5-4. NI-DAQmx Thermocouple Measurement Properties
Property
Short Name
Description
DAQ
Assistant
Accessible
Analog Input»Temperature»
Thermocouple»Type
AI.Thermcpl.Type
Specifies the type of
thermocouple
connected to the
channel.
Yes
Analog Input»Temperature»
Thermocouple»CJC Source
AI.Thermcpl.CJCSrc
Indicates the source of
cold-junction
compensation.
Yes
Analog Input»Temperature»
Thermocouple»CJC Value
AI.Thermcpl.CJCVal
Specifies the
temperature of the
cold-junction if the
CJC source is constant
value.
Yes
Analog Input»Temperature»
Thermocouple»CJC Channel
AI.Thermcpl.CJCChan
Indicates the channel
that acquires the
temperature of the
cold junction if CJC is
channel.
Yes
