National Instruments Module SCXI-1503 User Manual
Page 30
Chapter 3
Configuring and Testing
© National Instruments Corporation
3-5
6.
Click the Test button.
7.
Click the Start button.
8.
After you have completed verifying the channels, click the Stop
button.
You have now verified the SCXI-1503 configuration and signal connection.
Note
For more information on how to further configure the SCXI-1503, or how to use
LabVIEW to configure the module and take measurements, refer to Chapter 5,
