Creating Discs 51
If you choose not to print the test print, you will simply see the
alignment dialog box and can enter values to move the image.
The unit of measure is roughly 0.1mm. Making the Horizontal
Calibration number smaller or more negative will move the
image slightly to the left. Making the Horizontal Calibration a
larger value, or more positive will move the image to the right.
If the Vertical Calibration number is made smaller, or more
negative the image will move slightly up. If the Vertical
Calibration is set to a larger value, or more positive value, the
image will move down on the disc.
G. LABEL DESIGN REQUIREMENTS FOR OTHER
GRAPHICS PROGRAMS
While SureThing or Disc Cover will handle most labeling
needs, other graphics programs can be used to design labels
and print only directly to the Publisher.
When printing and burning through the PTPublisher software
your Publisher will support the following additional stardard
label image file formats: BMP, TIF, JPG, GIF, PNG and PRN.
These formats can be exported from most original graphics
formats such as Adobe Photoshop or Illustrator.
When creating images in other graphics programs we
recommend creating a 4.72 x 4.72 square image that has a
300 dpi resolution.
