42 Creating Discs
Inner Diameter
This value changes the size of the non-printed center. Larger
numbers cause the non-printed center to be larger and smaller
numbers make the non-printed center smaller. This number is
incremented by 0.1mm so a change of 10 for inner diameter
changes the diameter by 1mm. Set the diameter to 230 for
Primera TuffCoat media.
Cartridge Alignment
The Cartridge Alignment prints a test print and then automati-
cally scans the print to configure your printer for bidirectional
printing and to align the color and black cartridges for
Color+Black printing. It is important to perform this calibration
every time you change a cartridge. If you forget to perform this
calibration you will be prompted to do so before your first
print from the new cartridge.
Center The Print Image
NOTE: Your printer comes from the factory pre-calibrated to print
the image in the center of the CD. You can use this adjustment if you
need to fine-tune this location.
If you ever wish to verify your factory-calibrated Vertical
and Horizontal calibration settings, you can run a simple
calibration procedure to assure that your images will be
centered when printed on a CD. To do this, refer to the
following steps:
1. Verify that a disc and a color ink cartridge are installed
in the Publisher. It is important to use the same disc you
normally use for your publishing because different brands
of discs may vary slightly in size. Also, verify that the
Publisher is powered ON and that it is connected to your
computer.
2. Click on the Center the Print Image and then the
Properties button. The printer will begin printing the
calibration test print.
