9. Help
83 For assistance, please visit http://www.panasonic.com/consumersupport
Case 2:
When the recording paper has jammed
near the fuser unit:
1. Lift both green levers (
1) until they stop.
2. Remove the jammed paper ( 1) carefully
by pulling it upwards.
3. Push back the green levers ( 1) to the
original position.
Case 3:
When the recording paper has jammed
near the output tray:
1. Pull and hold the green lever (
1) to
release the jammed paper.
2. Remove the jammed paper ( 1) carefully
by pulling it upwards.
3 Close the top cover, holding the cover
release lever (
1). Then push the left side
(
2) of the cover release lever firmly, until
locked.
1
1
1
1
1
1
2
