Hotwire Menus and Screens
2-5 8000-A2-GB26-10 January 1999
Hotwire Menu Hierarchy
This section describes the menu structure of the Hotwire user interface.
Hotwire Chassis Main Menu
The following illustration shows the Hotwire Chassis Main Menu.
Hotwire Chassis
A. Chassis Info
B. Card Selection
C. Logout
97-15566-01
From the Hotwire Chassis Main Menu, you can select:
H
A. Chassis Info to enter or display chassis information, such as the chassis
name, name of person responsible for the system, and physical location of
the chassis.
H B. Card Selection to select a particular card in the chassis. This screen also
displays status information about all cards in the chassis. The card you select
determines which Hotwire menu the system will display next (Hotwire – DSL
menu).
For more information, see Card Selection Screen on page 2-10.
H
C. Logout to exit from the current login session on the Hotwire DSLAM.
For more information, see Exiting from the System on page 2-12.
Hotwire – MCC Menu
After selecting the MCC card from the Card Selection screen, the DSLAM system
displays the Hotwire – MCC Menu. From this menu, you can configure, monitor,
run applications, and troubleshoot the MCC card.
For information on the MCC card, see the Hotwire Management Communications
Controller (MCC) Card, IP Conservative, User’s Guide.
