C H A P T E R
4
O
PERATION
This chapter contains information on how to use the Powerware 9150,
including UPS shutdown, maintenance bypass operation, and UPS
communication.
Control Panel Functions
The control panel contains the UPS ON/OFF switch, the Battery Start
pushbutton, and the LED panel. The control panel shows the status of
the operation and generates an audible alarm (see Figure 14). The LED
panel contains the UPS indicators and the RESET pushbutton (see
Figure 15).
|
X2
Battery Start
UPS ON/OFF
LED Panel
Communication Ports
®
Figure 14. Powerware 9150 Control Panel
